Virutex Elastic clamping device ATU317S 1745928

Description

Elastic Frame • Dual Suction Mount • Multi-Angle Panel Gluing

Virutex Elastic Clamping Device ATU317S 1745928

An elastic-frame clamping device for fixing two panels at varying angles during gluing operations. Dual suction bases anchor to flat surfaces while the elastic tension system distributes consistent pressure across angled joints without rigid fixturing.

Applications

• Angular panel gluing and bonding
• Furniture and cabinet assembly with non-parallel joints
• Custom woodworking requiring angled panel alignment
• Installation work involving irregular or non-linear panel positioning

The angular counterpart to the ASU317S, built for glue-ups where panels meet at an angle rather than flat.

Specifications

Construction & Performance

• Elastic frame system flexes to accommodate varying joint angles while maintaining consistent clamping pressure throughout the cure.
• Dual suction bases anchor to flat surfaces without edge access, keeping both panels locked in position.
• Elastic tension pressure distribution applies even force across angled surfaces where rigid clamps create uneven contact.
• Dual ergonomic handles allow controlled positioning and adjustment when setting angle before suction is engaged.
• Heavy-duty metal construction maintains holding force through repeated glue-up cycles.

Why the ATU317S

• Elastic frame handles joint angles that rigid clamps cannot accommodate without racking or uneven pressure.
• Suction mounting works on the panel faces, so edge geometry does not limit clamping access.
• Consistent pressure across angled surfaces reduces voids and glue joint failures.
• Pairs with the ASU317S for shops that handle both flat and angled panel assembly.
