2,850W Hot Air System • No Compressed Air Needed • AK97NW Dual-Side Trimmer
Virutex EB10C Compact Edgebander 5100097
A 2,850W compact edgebander that activates pre-glued PVC, melamine, and veneer tapes via hot air, with no compressed air or dust extraction required. Ready in approximately 2 minutes, with electronic temperature control to 500°C, motorized dual-side trimming via the AK97NW unit, automatic end trimming, and foot pedal rear trimming for curved panels.
Applications
Edgebanding with pre-glued PVC, melamine, and veneer tapes
Straight and curved panel processing
Furniture manufacturing, cabinetry, and panel finishing
Compact workshops and locations without compressed air infrastructure
Plug into a standard outlet and start banding in 2 minutes — no compressed air line or dust collection hookup required.
Specifications
Part Number
5100097
Input Power
2,850 W
Voltage
200 – 250V, 50Hz (1 Phase)
Edging Thickness Range
7 – 65 mm
Temperature Control
0 – 500°C (Electronic)
Trimming Unit
AK97NW Motorized Dual-Side
Dimensions
600 x 950 x 430 mm
Weight
35 kg
Construction & Performance
Hot air activation system bonds pre-glued tapes without a glue pot, eliminating glue pot maintenance, warm-up waste, and adhesive inventory management.
Electronic temperature control to 500°C adjusts heat output to match tape material and thickness for consistent activation across different edge band types.
2-minute heat-up time gets the machine production-ready faster than glue pot systems that require longer warm-up cycles.
AK97NW motorized dual-side trimming unit finishes both faces of the panel edge simultaneously for clean, accurate results without a separate trimming pass.
Automatic end trimming cuts the trailing tape edge cleanly at the end of each panel.
Foot pedal rear trimming gives operator-controlled trimming on curved and irregular panel profiles where automatic cutting cannot follow the geometry.
No compressed air or dust extraction required allows installation anywhere with a standard power outlet, without infrastructure investment.
Why the EB10C
Hot air system eliminates glue pot maintenance entirely, a meaningful daily time saving in high-frequency production environments.
No compressed air requirement removes the infrastructure barrier that prevents smaller shops from running a dedicated edgebander.
Foot pedal rear trimming is a specific capability for curved panel work that many compact edgebanders in this class lack.
2-minute heat-up means the machine doesn’t need to run idle between jobs to stay at temperature, reducing energy use.
