Reid Lifting T-Davit Winched Column 3 Beam 1 up to 1100lb Capacity US-TDWA3A1
Product Description
Lightweight portable Winch READY aluminium davit includes shackle lifting points. Provides 52″ HOL at 39″ radius (pos A) & 64″ HOL at 36″ radius (pos B). WLL loading option to be selected. Total assembled weight (excluding winch) approx 74lbs
TDW has been designed primarily for goods and personnel lifting applications. It is also tested as a fall protection anchor device.
Meets the requirements of IRATA ICOP. The TDW is suitable for use with our range of sockets and portable bases.
Features
Complies with AS/NZ 5532:2013 Manufacturing Standards for Single Point Anchor Devices. Designed for Limited Free Fall Arrest Anchoring
Meets the requirements of AS/NZS 1891.4:2009 Industrial Fall Arrest Systems & Devices
Meets the requirements of IRATA ICOP
ATEX certified [Zone 2 standard, Zone 1 as an option]
Fall arrest capacity – 1 user
Personnel capacity up to 300kg and goods capacity up to 600kg
Sheave front and rear of beam for winch rope or winch cable
Double shackle head for lifting or attachment of PPE
Winch bracket options available for a variety of winches and retrieval SRL’s
Suitable for use with our range of sockets and portable bases
Configurations
The TDW is available in several standard configurations to meet with customers most common requirements.
