Straddle Stacker | 1100 lbs. Capacity | 63” Lift Height | Apollolift A-3004

Description

Apollolift Straddle Legs 1100lbs Cap. 63″ Lift Height A-3004

---

Product Description

The Apollolift Straddle Legs with a 1100lbs Capacity and 63″ Lift Height, identified as model A-3004, offers a versatile and efficient solution for material handling tasks across diverse industrial settings. Engineered for durability and performance, this stacker features a sturdy construction capable of safely lifting loads of up to 1100lbs.

Equipped with straddle legs, the A-3004 ensures stability and easy maneuverability around pallets and tight spaces, enhancing operational flexibility. With a lift height of 63 inches, it provides access to elevated storage areas, facilitating efficient stacking and retrieval of goods.

This stacker is designed for ease of use and reliability, ensuring consistent performance in various material handling applications. Whether it’s stacking, transporting, or loading/unloading, the Apollolift A-3004 delivers dependable performance, contributing to increased productivity and workflow efficiency in warehouses, distribution centers, and manufacturing facilities.

Compact yet powerful, the Apollolift A-3004 is an essential tool for businesses seeking a reliable and cost-effective solution for their material handling needs, offering durability, versatility, and ease of operation in one compact package.

Features

• Foot Operated Pump: Lift Height nearly 1” per stroke
• Compact design for pallet, perfect stacking and pallet positioning as well as stocking and refilling shelves.
• High quality steel mast and strong steel construction ensures rigidity and durability
• High efficient pumps makes the control easier to operate
• Metal grid protects user from lift chains
• With safety wheel guard and brake system to ensure safety during operation
• Manually raise and lower loads with foot pump and handle operation.

Mast

• Lifting height: 63”
• Mast lowered height: 78.7”
• Mast extended height: 82.7”

Forks

• Adjustable width: 7.9-29.3”
• Thickness: 1.9”
• Width: 3.94”
• Length: 31.5”
• Fork lowered height: 2.8”

Straddle Legs

• Inner width: 51.1”
• Height: 4.3”

Dimensions

• Overall width: 60”
• Overall length: 52.7”
• Load center: 19.7”
• Recommended Aisle Width: 77.8″
• Turning radius: 47.2”
• Capacity: 1100 lbs
• Lifting Height: 63”
• Wheel Diameter: 5.8”
• Weight: 490 lbs

Warranty

Apollo Forklift offers a 1-year limited warranty starting from the date of product receipt. Please note that the warranty does not cover easy-wearing parts or damages caused by human error.
Our warranty commitment entails providing a replacement for any defective original part covered under the warranty.

1. Within the first 30 days of receipt, if the product exhibits any quality issues, we will provide free replacement parts and professional remote technical guidance. If our after-sale department determines that the product requires return for repair, all round-trip shipping costs will be covered by us.
2. Between 30 days and 1 year from receipt, should the product encounter any quality problems, we will provide free replacement parts and professional remote technical guidance. If repair necessitates return shipping, the customer will be responsible for half of the shipping costs.
3. After 1 year from receipt, free technical guidance will be available for any quality issues. However, customers will be required to cover the cost of replacement parts. Additionally, if the repair requires return shipping, the customer will incur related maintenance costs as well as all round-trip shipping charges, which will be provided upon request.

Please be aware that for spare parts orders, the warranty period is 3 months, and for batteries, it is 6 months.

As for USED MACHINES orders, they are subject to a No Return and No Refund Policy but come with a 6-month limited warranty covering parts only (labor not included).
