Peanut 1 Connectors – Box of 1000 (23¢ Each)

Description

The Peanut 1 connector is designed for manufacturers who have 3+ axis CNC nesting machines for 90º connections. With alternative applications of edge-to-edge connections as well.

The recess of the connector and the corresponding key hole are all machined on the face of the panel. As only face machining is required, manufacturers create all panels for furniture in one machining operation. The body shape is designed for fast machining, requiring only a 25mm and 5mm drill bit to create the recess for the connector. Bevelled edges make aligning the PEANUT 1 easy and the small 5mm notch guides the component into the perfect position. The PEANUT 1 is available in 8 colors, enabling it to blend with many wood finishes. Once inserted, all panels made with PEANUT® components can be packed flat and depending on the tightness of the joint, can be assembled with no tools.

Box Quantity: Box of 1,000 (~23¢ per)

Features

• A self-clamping, single component connector
• Only one CNC machining process
• Creates an incredibly strong joint
• Designed from glass fibre many times
• Quick and simple assembly

Additional Tooling:

Peanut 1 CNC Drill Pack, 5mm & 24.9 Drill Bits (Drills Holes for Peanut 1 Connectors)

Peanut Cutter with 1/2″ Shank for Peanut Connectors 1/2/3 (Creates a Keyhole Slot which has an Undercut)

Documents:

Peanut Slot Machining Options Brochure

Peanut 1 Connectors Spec Sheet

Technical Specs

Brand: Peanut

Material: Glass-Fiber Reinforced Nylon

Insertion Type: Dismountable

Finishes: Pure White (RAL 9010), Signal White (RAL 9003), Telegrey (RAL 7047), Fawn Brown (RAL 9007), Jet Black (RAL 9005)
