Oliver Edge Sander 9″ x 138.5″ (Oscillating)

Sale!
Oliver Edge Sander 9" x 138.5" (Oscillating)

Oliver Edge Sander 9″ x 138.5″ (Oscillating)

Original price was: $4,079.99.Current price is: $2,388.83.

89 in stock

SKU: 6320.003 Category:

Description

The Oliver 6320 is the ultimate edge sanding workhorse with a large 9″ x 138.5″ belt with adjustable oscillation action. The heart of this edge sanding marvel lies in its precision-balanced drums and a robust 3HP 3Ph TEFC motor. This dynamic duo ensures your woodworking experience is characterized by smooth, reliable operation, resulting in projects completed with impeccable quality efficiently.

Features

  • Large 9” x 138.5” belt features adjustable oscillation action for a superior finish
  • Tables are heavy cast iron and precision ground
  • Both tables adjust up and down for complete use of belt
  • Main table features spring assisted raising and lowering
  • End table allows contoured sanding applications
  • Drums are precision balanced for smooth operation
  • Built-in 4” port for efficient dust management
  • Magnetic Controls for added safety and motor protection
  • Powerful 3HP 3Ph TEFC motor

Included

  • Sanding Belt
  • Main Cast-Iron Main & Contour Table
  • Dust Port Diameter 4″
  • Miter Gauge
  • Stop Bracket

Specifications

Table Material Cast Iron
Main Table Size 13” x 46”
End Table Size 13” x 18” Radius Both Table Working Height 34-1/2” to 42-1/2”
Main Table Tilt 5° in 45° out
End Table Tilt Fixed
Belt Size 9” x 138.5”
Belt Speed Approx. 4,100 FPM
Oscillation 0, 40-60 per minute
Table Height 33″-40.5″
Oscillation Stroke 13/64″ – 25/64″
Dust Port Diameter 1 x 4″
Minimum CFM Required 650 CFM
Motor 3HP, 3Ph 230V Only (16.5 Amp)
Overall Dimensions 84“(L) x 40”(W) x 44”(H)
Net Weight 623 lbs.
