Magnetic Drill | Portable | Four-Gear | CS Unitec

Sale!
Magnetic Drill | Portable | Four-Gear | CS Unitec

Magnetic Drill | Portable | Four-Gear | CS Unitec

Original price was: $1,853.40.Current price is: $1,176.24.

30 in stock

SKU: MABasic 850 Category:

Description

CS Unitec Four-Gear Portable Magnetic Drill MABASIC 850

Product Description

Powerful motor for demanding jobs



Features

  • 4-gear, high-speed, powerful motor for demanding jobs
  • 3/4″ direct arbor with automatic cooling
  • Internal lubrication system

Safety

  • Simple, ergonomic arrangement of controls for one-handed operation

Specifications

Motor Power 16 Amp / 110 Volt
Weight 53 lbs.
Stroke 10″
Hole Capacity 3-1/16″ dia.
Twist Drill Capacity 1-1/4″ dia.
Speeds 1: 110 RPM
2: 175 RPM
3: 245 RPM
4: 385 RPM
4 Gears (4 gears)
Magnet Base Size 8-5/8″ L x 4-1/3″ W
Dimensions 19-3/8″ H x 11-5/8″ L x 8-1/4″ W
Magnetic Force (1″ plate) 6000 lbs.
Arbor Bore 3/4″ Weldon Shank
Spindle MT3
Internal Lubrication Included

Standard Equipment

  • 1 Magnetic drilling machine
  • 1 1/2″ chuck
  • 1 Pilot pin
  • 1 Carrying case

Standard Equipment also includes safety strap, carabin hook, allen keys, operating manual and warranty certificate.

Product Document

Brochure

Schematics

Operating Manual
