LAGUNA – X|FLUX: 5 DUST COLLECTOR

Description

The all-new X|Flux 5 boasts a powerful 5hp motor and impressive 1823 CFM.  Auto-cleaning of the HEPA filter is accomplished by double-paddles that sweep the filter every 3 minutes of system use in a clockwise and counterclockwise action.  Remote and LED drum light are standard. The X|Flux 5 is a full-size stationary, single-stage dust collection unit with convenient 39 gallon drum on locking castors.

Specifications:

Motor Specs:  5 HP

Electrical Specs:  220V / 60Hz / 1PH / 3450 RPM

Running AMP (8” inlet) 21.5 A at 220V

Air Volume:    1823CFM (cubic feet per minute)

Max. static pressure  12 Inches of water

Fan size    14.5”

Inlet:  8”

Decibel Reading: 69 dBA (@9.8ft)

Remote Control: High frequency

Collection capacity  39 gallon Octagon drum x 1 set

Packing Size:

(L x W x H)       35.4” x 28.3” x 81.5”

(90 x 72 x 207 cm)

Machine weight         456 lbs. (207 kgs)

Shipping weight         544 lbs. (247 kgs)

Assembled Dimensions:

(L x W x H)       36” x 38” x 91”

Filter Media   Filtering area: 32.3 sq/ft (3m2)

Cartridge Filter   HEPA 19.7” x 19.7” (50 x 50cm) x 1pc ; (0.3-0.4 micron @ 99.7% efficiency)
