Gedore Universal Puller Set, in L-BOXX 136 GED2838362

Description

Gedore Universal Puller Set, in L-BOXX 136 GED2838362

Product Description

The Gedore Universal Puller Set is a versatile professional extraction kit designed for demanding workshop and industrial applications. Featuring 2-arm and 3-arm pullers, rigid and slim pulling legs, extensions, and a durable L-BOXX 136 storage system, this high-performance set supports up to 5-ton pulling capacity and allows 12 puller combinations for maximum flexibility in confined spaces.

Includess: 1100 CT2-1.041100 L, Net weight [kg]: 6,3 kg, Parts list: Universal puller HIGH POWER No. 1.04/HP1A-B, 2-arm, 130×100 mmCross-beam No. 107/1A03, 3-arm 180 mmPulling leg No. 106/A-100-B, all-steel, leg brake3x extension No. 106/A-100-VB with leg brake 100 mm3x pulling leg No. 106/A-100-S, slim 100 mm3x pulling leg No. 106/S101-S, without clamping partSpindle No. 1.1406200, 17 M14x1,5 200 mm+ GEDORE L-BOXX® 136 No. 1100 L; With 2- and 3-arm cross-beam With rigid and slim legs and extensions Extra slim Pulling hooks for narrow installation spaces are included for self-installation The forged hooked feet are particularly suitable for difficult-to-access places 12 different pullers can be combined Outside   up to 130 mm, inside   up to 170 mm with a clamping depth of 200 mm With check tool insert for quick identification of missing tools No. 1100 CT2-1.04 for retrofitting existing L-BOXX®s 136

Features

• Max. capacity up to 5 t 2- and 3-arm cross-beam
• With rigid and slim legs and extensions
• Extra-slim pulling legs for cramped spaces are attached for self-mounting
• The forged leg feet are very slim particularly suitable for barely accessible places
• 12 different pullers can be combined
• External up to 130 mm, internal up to 170 mm with a 200 mm clamping reach
• With Check-Tool insert for quick check of completeness
• As tools are fully sunk in the foam, the equipped insert can be stacked
• Insert for use in drawers with min. dimensions 400 x 310 x 60 mm
