Hawk Enterprises 13” Extra Heavy Duty Floor Machine F23-01
Product Description
The Hawk XHD provides maximum power with the twin capacitor AC motor and Hawk’s ruggedly reliable floor machine size. 100% motor construction for years of reliable service. The XHD is powered by the 1.5 HP motor and offered with a wide range of tools, accessories and optional weights.
The optional DX package adds the 4 gallon solution tank, custom fit splash guard and premium pad driver.
Power
1.5 HP, 66 frame, dual capacitor AC motor
115V, 60 Hz Power. (230V optional).
50 ft. (12-3) industrial cord w/ molded plug
XHD (Extra Heavy Duty) triple-planetary 11:1 helical-cut industrial gears, case hardened with steel coupler.
Engineered Design
All steel, welded, powder-coated frame
One piece heavy-duty chromed steel handle with variable position positive handle lock and vinyl-dipped foam grips
13″, 15”, 17” and 20” chromed steel brush covers with wraparound bumper. Dual steel operating triggers.
Negative pressure on/off switch.
Thumb-operated safety switch.
1” x 5” non-marking ball bearing wheels
Safety Features
Quiet 66 dB operation. Meets GS42 requirements.
UL/CUL listed
Specifications
Model
HP1513-XHD
Part
F23-01
Machine Size
13 inch
Pad Size
12 inch
Pad Speed
165 RPM
Amp Draw
5.3 Amp
Weight
87 lbs
All Sizes
Motor
1.5 HP, 66 frame, dual capacitor AC chrome cover moto
