Associated 6042 Electrical System Tester 12/24V 500A Digital

Description

Features and Benefits:

• 500 Amp safety clamps with “Flexi-Spring” and patented side terminaladapter plus separate light gauge test leads for tighter spots
• Heavy-duty single extruded leads for testing up to 15 feet apart
• 6043 AC/DC Current Sensing Inductive pickup INCLUDED
• 10-meg ohm input impedance for today’s high tech systems
• Convenient heavy-duty tilt back cart with 8 inch wheels and 2 trays included

Designed with the highest quality and versatility in mind. Interpretsdata from the charging/starting system on easy-to-read LED displayvoltmeter and ammeter. Also shows +/- Amps for easy diagnosis of currentleakage problems. The 500 Amp carbon pile variable load capabilityprovides accurate load testing for up to 1000 CCA batteries. Circuitsprotected against reverse voltages due to incorrect hookup. “LOAD ON”light indicates the load is activated. Spring loaded to shut-offautomatically. MADE IN USA.

Specifications:

Load: 500 A

Ammeter: Digital 0-999A

Voltmeter: Digital LCD 0-32.0 V DC

Leads: 8’ 4 AWG

Clamps: 500 A

Limited warranty: 1 YEAR

Shipping dim. (HxWxD): 8”x36”x19”

Weight: 67 LBS.
