20″ HELICAL CUTTERHEAD FOR PLANERS

Description

Upgrade a compatible 20″ thickness planer with the Craftex CXHEL20 Helical Cutterhead. Designed as an alternative to a conventional straight-knife cutterhead, it uses four rows of replaceable carbide inserts to produce a smooth surface finish across the full 20″ cutting width.

The cutterhead is equipped with 100 carbide inserts measuring 15 x 15 x 2.5 mm. Individual inserts can be replaced when required, eliminating the need to replace a full-length planer knife. Replacement inserts are available under part number CXHCINS.

Confirm your planer’s exact brand and model against the compatibility list before ordering.

Features

• Upgrades compatible 20″ thickness planers to a helical carbide insert cutterhead
• Four-row cutterhead design provides consistent cutting coverage
• Equipped with 100 replaceable carbide inserts
• Produces a smooth surface finish
• Individual inserts can be replaced as needed
• Eliminates the need for conventional full-length planer knives
• Supports a maximum cutting width of 20″
• Compatible with select Craftex, Grizzly and King planer models
• Uses CXHCINS replacement carbide inserts

Specifications

• Brand: Craftex
• Model: CXHEL20
• Product Type: Helical cutterhead
• Maximum Cutting Width: 20″
• Cutterhead Diameter: 81 mm
• Number of Insert Rows: Four
• Number of Carbide Inserts: 100
• Carbide Insert Size: 15 x 15 x 2.5 mm
• Replacement Insert Part Number: CXHCINS

Compatibility

• Craftex CX20
• Craftex CX20SC
• Craftex CX20HC
• Grizzly G0454
• Grizzly G0454Z
• Grizzly W1754
• Grizzly W1754S
• Grizzly ST1014
• King KC-520C

Comes With

• CXHEL20 helical cutterhead
• 100 carbide inserts

FAQ

What is the CXHEL20 used for?

The CXHEL20 is designed to replace or upgrade the cutterhead in compatible 20″ thickness planers.

How many carbide inserts are installed?

The cutterhead uses 100 replaceable carbide inserts arranged in four rows.

What size inserts does the cutterhead use?

It uses carbide inserts measuring 15 x 15 x 2.5 mm.

Which replacement inserts fit this cutterhead?

The CXHEL20 uses Craftex CXHCINS replacement inserts.

What is the maximum cutting width?

The cutterhead supports a maximum cutting width of 20″.

Will the CXHEL20 fit any 20″ planer?

No. Compatibility is model-specific. Confirm that your planer’s exact brand and model appears in the compatibility list before ordering.

Does this cutterhead fit Craftex CX20-series planers?

Yes. It is listed for the Craftex CX20, CX20SC and CX20HC.

Are installation components included?

The supplied information does not confirm whether bearings, mounting hardware or installation tools are included.
