1″ X 30″ BELT & DISC SANDER

Description

The CT170N is a compact combination belt and disc sander designed for a range of workshop sanding tasks. Its 1/3 HP, 120V induction motor drives both the 5″ sanding disc and 1″ x 30″ sanding belt at 3400 RPM for efficient material removal.

Both work tables tilt from 0° to 45°, allowing for bevel sanding and angled work. A single-knob belt tracking adjustment helps keep the sanding belt properly aligned, while the solid steel base and four rubber feet help reduce vibration during operation.

For improved dust collection, the CT170N is equipped with two 1-3/4″ dust ports. Its compact format makes it well suited for contour sanding, detail and intricate work, and dry sharpening applications.

Features

• Combination 1″ x 30″ belt and 5″ disc sander

• 1/3 HP induction motor

• 3400 RPM no-load speed

• 0° to 45° tilting work tables

• Single-knob belt tracking adjustment

• Solid steel base

• Four rubber feet help reduce vibration

• Two 1-3/4″ dust ports

• Suitable for contour sanding

• Suitable for detail and intricate sanding work

• Suitable for dry sharpening

• Includes miter gauge

• Includes sanding belt and sanding disc

• 2-year warranty

Specifications

• Model: CT170N

• Brand: Craftex

• Motor Type: Induction

• Motor: 1/3 HP

• Voltage: 120V

• Frequency: 60 Hz

• Amperage: 2.3A

• No-Load Speed: 3400 RPM

• Sanding Disc Diameter: 5″

• Sanding Disc Grit: 80

• Sanding Belt Size: 1″ x 30″

• Sanding Belt Grit: 100

• Dust Ports: 2 x 1-3/4″

• Table Tilt: 0° to 45°

• Weight: 8.5 kg

• Warranty: 2 years

Comes With

• CT170N Belt and Disc Sander

• Miter gauge

• 100-grit 1″ x 30″ sanding belt

• 80-grit 5″ sanding disc

• User manual

FAQ

What size sanding belt does the CT170N use?
The CT170N uses a 1″ x 30″ sanding belt.

What size sanding disc does it use?
It uses a 5″ sanding disc.

Can the work tables be tilted?
Yes. The tables tilt from 0° to 45° for angled sanding.

What type of motor does the CT170N have?
It is powered by a 1/3 HP, 120V induction motor.

Does the sander have dust collection ports?
Yes. It has two 1-3/4″ dust ports.

What applications is this sander suited for?
It is suitable for contour sanding, detail and intricate sanding work, general stock removal, and dry sharpening.

Are sanding abrasives included?
Yes. The unit includes a 100-grit 1″ x 30″ sanding belt and an 80-grit 5″ sanding disc.

What warranty is included?
The CT170N includes a 2-year warranty.
